AS380-MB Elevator Main Power Box
A compact elevator main power-distribution box with separate main-supply, well-light and car-light protection and an integrated service socket.
Product Model and Features
Commercial modelAS380-MB
Product identityAS380-MB Elevator Main Power Box
Product View
Product Information and Specifications
| Item | Information |
|---|---|
| Product type | Elevator main power-distribution box |
| Model | AS380-MB |
| Supplier product reference | TSZJG-2A05J |
| Supply | 220 V AC, 50 Hz |
| Rated insulation voltage | 500 V |
| Impulse withstand voltage | 4 kV |
| Protection rating | IP30 |
| Main circuit breaker | 32 A |
| Well-light circuit breaker | 16 A |
| Car-light circuit breaker | 16 A |
| Socket outlet | 220 V AC |
Before You Buy
- Match the AS380-MB identity and the TSZJG-2A05J supplier reference.
- Check the 220 V supply and the listed breaker arrangement against the electrical design.
- Confirm enclosure mounting, cable entries, earthing and terminal connections before installation.
Frequently Asked Questions
Which supply is specified for AS380-MB?
The listed supply is 220 V AC at 50 Hz.
Which circuit-breaker ratings are shown?
The configuration lists a 32 A main circuit breaker and separate 16 A breakers for well lighting and car lighting.
Which enclosure ratings are listed?
The product data lists 500 V rated insulation voltage, 4 kV impulse withstand voltage and IP30 enclosure protection.
