One-way roller actuation
The horizontal roller arm is intended for actuation from the specified direction. Confirm cam approach, overtravel and release path.
D4N-series compact limit switch with horizontal one-way roller arm, 1 NC + 1 NO snap-action contacts, terminal-block connection and one bottom Pg13.5 conduit entry.
The product photographs used below show D4N-1162 on the physical label. Five distinct views support comparison of the roller arm, nameplate, mounting slots, terminal housing and bottom conduit entry. A separate manufacturer page used a D4N-1A62 representative photograph; that conflicting image is not used here.
| Item | Reviewed exact-model reference | Order check |
|---|---|---|
| Model | D4N-1162 | Match the complete physical label |
| Actuator | Horizontal one-way roller arm lever | Confirm travel direction, roller position and cam geometry |
| Contacts | 1 NC + 1 NO | Verify terminal assignment and required control logic |
| Switching action | Snap action | Do not substitute the D4N-1A62 slow-action variant |
| Connection | Terminal block | Confirm conductor size, terminals and wiring method |
| Conduit entry | One bottom entry, Pg13.5 | Confirm thread, gland, cable diameter and sealing |
| Housing | Plastic | Check mounting and environmental compatibility |
| Contact finish | Gold clad, 3 µm | Confirm suitability for the actual control circuit |
| Label load references | AC-15: 3 A / 240 VAC; DC-13: 0.27 A / 250 VDC | Confirm actual load, inrush and protective device |
| Degree of protection | IP67 reference | Depends on complete installed sealing |
| Distributor dimension reference | 31 × 31.5 × 83.6 mm | Measure actual unit and confirm current drawing |
| Ambient temperature reference | −30 to +70 °C | Confirm actual site conditions |
| Mechanical-life reference | 15,000,000 operations | Actual life depends on alignment, travel and duty |
Technical values are retained as exact-model or label references, but they do not establish the origin, condition or traceability of the supplied stock. Verify the physical unit and current documentation before use.
The horizontal roller arm is intended for actuation from the specified direction. Confirm cam approach, overtravel and release path.
The D4N-1162 reference identifies snap action with 1 NC + 1 NO contacts. Do not replace it with the similarly named D4N-1A62 slow-action version.
The one-conduit housing uses a bottom Pg13.5 entry. Match the gland thread and installed sealing components.
Check horizontal one-way roller orientation, operating position, travel, overtravel, release force, mounting slots and available clearance.
Verify 1 NC + 1 NO snap action, terminal assignment, voltage, utilization category, load current and inrush.
Request the actual D4N-1162 nameplate, terminal block, conduit thread and traceability documents when manufacturer origin or certification matters.
No. The reviewed references identify D4N-1162 as snap action and D4N-1A62 as a different slow-action variant.
No. Match the complete model, roller direction, contact action, terminal arrangement, conduit entry and mounting dimensions.
No. The final protection level depends on the gland, cable, sealing, mounting and condition of the actual unit.
