SH-EI100H35-1024-BR30Y1
Product code SH-01150028. The model and specifications below are matched to the current independent-store record and the newly supplied product material.
Product views
Specifications and functions
| Product | Elevator hollow-shaft rotary encoder |
|---|---|
| Exact model | EI100H35-1024-BR30Y1 |
| Resolution | 1024 PPR |
| Shaft family | 35 mm hollow-shaft family |
| Included view | Encoder body, attached cable and connector are shown in the exact-model source image |
| Selection | Confirm the complete suffix, connector pinout, cable length and electrical output before ordering |
Selection and installation
Confirm the exact model, power/voltage class, connector arrangement and system generation before ordering. Installation and commissioning must be performed by qualified elevator personnel using the applicable system documentation.
