Oil Buffer

Name: Oil Buffer
Brand: 无
SKU: SH-02020043
Price: 0.29 USD
Availability: InStock

≤1.0m/s

السعر

$0.29

/قطعة

$0.30

سعر مرجعي لا يشمل التركيب والشحن، يرجى استشارة فريق المبيعات للحصول على عرض سعر دقيق

اختر الموديل

SH-HYF80F

📞 استفسار فوري

ⓦ أرسل لنا رسالة

مقدمة المنتج

ELEVATOR HYDRAULIC BUFFER

HYF80F Elevator Buffer

A fully enclosed hydraulic buffer with 80 mm stroke, integrated safety-switch arrangement and a four-hole base for elevator pit installation.

Product and Technical Views

HYF80F hydraulic buffer product view — HYDRAULIC BUFFER ASSEMBLY

HYF80F dimensional outline — MOUNTING AND OUTLINE REFERENCE

Fully enclosed structure

The enclosed cylinder and base arrangement supports elevator pit installation.

Safety-switch bracket

The side-mounted mechanical arrangement provides a visible position for the safety switch.

Four-hole base

The base uses a 90 × 90 mm mounting pattern with four Ø14 mm holes for HYF80F.

HYF80F Specifications

Item	Specification
Model	HYF80F
Rated speed	≤ 1.00 m/s
Permitted P+Q	600–3000 kg
Buffer stroke	80 mm
Free height	315 mm
Mounting pattern	90 × 90 mm
Mounting holes	4 × Ø14 mm
Structure	Fully enclosed hydraulic buffer

F-Series Model Comparison

Model	Rated speed	Permitted P+Q	Stroke	Free height	Mounting
HYF80F	≤1.00 m/s	600–3000 kg	80 mm	315 mm	90×90, 4×Ø14
HYF175F	≤1.60 m/s	700–3000 kg	175 mm	520 mm	90×90, 4×Ø14
HYF210F	≤1.75 m/s	600–3500 kg	210 mm	606 mm	90×90, 4×Ø14
HYF275F	≤2.00 m/s	860–3500 kg	275 mm	760 mm	150×100, 4×Ø14
HYF425F	≤2.50 m/s	860–3500 kg	425 mm	1125 mm	150×100, 4×Ø14

Before Ordering

Capacity match

Confirm rated speed and permitted P+Q against the elevator configuration.

Dimensional match

Check stroke, free height, base pattern and pit clearance before installation.

Safety-switch setup

Confirm the required switch actuation position and controller safety-circuit connection during commissioning.

Selection note: model rows are series comparisons; order the exact model that matches the required speed, load range, stroke and mounting pattern.

Frequently Asked Questions

What are the main HYF80F selection values?

HYF80F is listed for rated speed up to 1.00 m/s, permitted P+Q of 600–3000 kg, 80 mm stroke and 315 mm free height.

What mounting pattern is used?

The HYF80F mounting pattern is 90 × 90 mm with four Ø14 mm holes.

Can another F-series model be substituted directly?

Not without checking the full row. Speed, permitted P+Q, stroke, free height and mounting pattern vary across the F series.
