SH-MDKE6
Product code SH-01200059. The model and specifications below are matched to the current independent-store record and the newly supplied product material.
Product views
Specifications and functions
| Product | MDKE6 handheld operator / commissioning panel |
|---|---|
| Display | 5-digit LED display for parameter codes and status |
| Connection | Standard RJ45 interface using an 8-core network cable |
| Supply | DC 5 V ±5%, supplied by the connected controller |
| Overall size | Approximately 117 × 65 × 19 mm |
| Mounting opening | Approximately 110 × 58 mm when panel-mounted |
| Controls | Eight-key local operating keypad |
| Compatibility | Used with compatible NICE3000new, NICE5000, NICE1000+ and related Monarch systems |
Selection and installation
Confirm the exact model, power/voltage class, connector arrangement and system generation before ordering. Installation and commissioning must be performed by qualified elevator personnel using the applicable system documentation.
