Product Overview
The views below show the reviewed product structure, fork opening and rear housing. The label photograph and screenshots containing parameter tables remain verification evidence only and are not displayed as product imagery.
FORK-TYPE PROFILE
SENSING FORK OPENING
REAR HOUSING VIEW
Specification Confirmation
| Item | Reviewed reference | Order check |
|---|
| Inventory model | GLS126NT2.NC.NO | Confirm the complete physical nameplate and required output state |
| Sensor structure | Fork-type elevator leveling sensor | Confirm vane position and mounting orientation |
| Fork gap | 26 mm — GLS 126 family reference | Check the actual vane width and travel clearance |
| Maximum response time | 1 ms — GLS 126 family reference | Confirm the exact supplied electrical version |
| Maximum repeatability error | 0.5 mm — GLS 126 family reference | Installation alignment and vane geometry also affect leveling |
| Housing / enclosure | ABS / IP66 — GLS 126 family reference | Confirm site exposure and connector sealing |
| Ambient temperature | −20 to +60 °C — GLS 126 family reference | Confirm the installation environment |
The manufacturer sheet covers several GLS 126 electrical variants and does not name the full NT2.NC.NO suffix. Supply voltage and output wiring are therefore intentionally not fixed here; verify them from the supplied unit and project interface.
Buyer Confirmation Checklist
Nameplate and output
Provide a clear label photo and confirm whether the controller requires normally closed, normally open or paired outputs.
Mechanical interface
Check fork gap, vane width, mounting holes, cable exit direction and available installation clearance.
Electrical interface
Confirm the actual supply voltage, wire assignment, output logic and controller input before replacement.
Frequently Asked Questions
Can any GLS 126 sensor replace this version?
No. The family includes different electrical versions. Match the complete nameplate, output logic, wiring and cable configuration.
What should be supplied for compatibility review?
Send the sensor label, front and rear photos, wiring connection, mounting position, vane dimensions and controller input details.
Why are voltage and wiring values not listed as fixed?
The reviewed manufacturer sheet covers multiple family variants with different electrical ranges. The exact supplied unit must be confirmed first.
Selection note: Final compatibility depends on the complete supplied model, output state, controller interface, cable version, mounting geometry and leveling vane.
