SH-MCP-ST KC75
Product code SH-01190090. The model and specifications below are matched to the current independent-store record and the newly supplied product material.
Product views
Specifications and functions
| Product | STEP MCP-ST KC75 integrated elevator control cabinet |
|---|---|
| Backend configured power | 30 kW |
| Architecture | Elevator logic controller, drive, electrical switching and safety monitoring integrated in one cabinet |
| Motor support | Permanent-magnet synchronous and AC induction traction motors, subject to configuration |
| Brake control | KC75 control configuration uses DC 110 V pull-in and DC 75 V holding voltage |
| Operation | Automatic motor tuning and commissioning support |
| Selection note | Confirm the exact cabinet power hardware and brake-voltage configuration against the project before ordering |
Selection and installation
Confirm the exact model, power/voltage class, connector arrangement and system generation before ordering. Installation and commissioning must be performed by qualified elevator personnel using the applicable system documentation.
