Product Features
A networked smoke detector for monitored equipment rooms and other controlled indoor environments.
Product Information and Specifications
| Product type | Networked smoke detector |
|---|
| Model | TAD-169 |
|---|
| Supply | DC 9–35 V or AC 220 V |
|---|
| Standby current | ≤4 mA at DC 12 V |
|---|
| Alarm current | ≤25 mA at DC 12 V |
|---|
| Alarm output | Relay output with LED alarm indication |
|---|
| Operating temperature | -10 to +50 °C |
|---|
| Coverage guidance | One detector per 20–30 m² |
|---|
| Dimensions | Ø104 × 51 mm |
|---|
Before Ordering
Select the supply arrangement and alarm interface required by the monitoring system, and position detectors according to the protected area and installation design.
Frequently Asked Questions
What supply options does TAD-169 support?
The verified manufacturer specification lists DC 9–35 V or AC 220 V.
How is an alarm indicated?
The detector provides a relay alarm output and LED alarm indication.
What area can one detector cover?
The manufacturer guidance is one detector per 20–30 square metres, subject to the installation layout and applicable project requirements.
