DO3000 Elevator Door Operator Controller
Frequency-conversion controller for the DO3000 permanent-magnet synchronous-motor door-operator system.
Product Model and Features
DO3000
- Door-width operating range from 700 to 1800 mm
- AC 220 V controller input with variable-voltage, variable-frequency motor output
- Designed around an AC 80 V, 94 W permanent-magnet synchronous motor
Product View
Product Information and Specifications
| Product type | Permanent-magnet synchronous-motor frequency-conversion door operator |
|---|---|
| Commercial model | DO3000 |
| Net door width range | 700–1800 mm |
| Controller input | AC 220 V ±20%, 50/60 Hz |
| Controller output | 0–220 V, 0–50 Hz |
| Motor rated voltage | AC 80 V |
| Motor rated speed | 180 r/min |
| Motor rated power | 94 W |
| Full-current operating altitude | Below 1000 m |
| Altitude derating | 95% at 1000–2000 m; 85% at 2000–3000 m |
| Maximum relative humidity | 95% under the manual’s stated monthly-temperature condition |
| Supply fluctuation working condition | Within ±15% |
Before You Buy
Confirm the complete controller part number and hardware revision before wiring. DO3000 controller revisions use different input/output terminal assignments; the physical label and matching wiring diagram must be used for the supplied unit.
Frequently Asked Questions
Which door width range is covered by DO3000?
The DO3000 manual specifies a net door-width range of 700–1800 mm.
What are the controller and motor ratings?
The controller accepts AC 220 V ±20% at 50/60 Hz and provides 0–220 V, 0–50 Hz output for an AC 80 V, 180 r/min, 94 W motor.
Can one terminal map be used for every DO3000 controller?
No. Terminal assignments vary among the covered controller revisions. Match the physical part label and its corresponding wiring diagram before installation.
