Photoelectric Switch
Photoelectric SwitchPhotoelectric SwitchPhotoelectric Switch

Photoelectric Switch

Photoelectric Switch

Price
$14.69
/pc
$15.15
Reference price excluding installation & freight,please consult sales for exact quote
Select Model
SH-SGD31-GG-T2282P
📞 Instant Inquiry
ⓦ Send Message
Product Introduction
ELEVATOR LEVELING SENSOR

SGD31-GG-TZ2B2P Photoelectric Switch

A U-shaped photoelectric leveling and position switch with DC 12–30 V operation, fast response and separate NPN and PNP output leads.

Product Views and Features

Three product views show the complete cable, sensing slot, mounting holes, label and four wire leads.

SGD31-GG-TZ2B2P complete view with cable
COMPLETE VIEW WITH CABLE
SGD31-GG-TZ2B2P front view
FRONT VIEW AND SENSING SLOT
SGD31-GG-TZ2B2P reverse view with wire leads
REVERSE VIEW AND WIRE LEADS

U-shaped sensing slot

The open slot accepts the elevator leveling vane without mechanical contact.

Dual output leads

Separate yellow NPN and white PNP output wires support the applicable controller input.

Two mounting points

The housing provides two visible mounting holes for stable positioning and alignment.

Product Information

ItemSpecification
ModelSGD31-GG-TZ2B2P
Product typeU-shaped photoelectric leveling / position switch
Working voltageDC 12–30 V
Response time≤ 1 ms
Red wireDC 12–30 V
Black wire0 V
Yellow wireNPN output
White wirePNP output
HousingOrange U-shaped housing with two mounting holes

Working Principle

Opposed optical elements monitor the open slot. When an opaque leveling vane enters the slot, it interrupts the optical path and changes the selected output state for the elevator controller.

Before Ordering

Electrical match

Confirm DC 12–30 V and the required NPN or PNP controller input before wiring.

Mechanical match

Compare the housing, two mounting holes, sensing-slot position and cable route with the installation.

Installation check

Align the vane through the center of the slot without contact, then verify the output change during commissioning.

Wiring note: isolate power before connection and follow the visible red, black, yellow and white wire functions.

Frequently Asked Questions

Does the switch provide both NPN and PNP outputs?

Yes. The yellow wire is the NPN output and the white wire is the PNP output.

What supply range is required?

Use DC 12–30 V, with red for the supply and black for 0 V.

What should be checked before replacement?

Confirm the complete model, supply range, required output logic, mounting-hole pattern, sensing-slot alignment and cable routing.
