Product Introduction

NJK5002AB Four-Wire PNP Magnetic Proximity Switch

The NJK5002AB is a four-wire PNP magnetic-proximity switch selection with separate normally-open and normally-closed outputs. Match the magnetic target, threaded fixing arrangement and connection requirements to the installation. Product views include a complete cable assembly and short-body mounting close-ups.

Product Views

Sensor and complete cable assembly with magnetic-target example
Sensor and complete cable assembly with magnetic-target example
Short threaded-body front close-up
Short threaded-body front close-up
Alternate short-body mounting close-up
Alternate short-body mounting close-up
Short-body indicator and cable-exit close-up
Short-body indicator and cable-exit close-up

Outline Dimensions

Short-body outline and mounting dimensions
Short-body outline and mounting dimensions

Short-body outline drawing. Dimensions in mm: body length 25, end-view dimension Ø21, nut width 17 and fixing detail 3. Thread M12 × 1. Two clamp nuts, two washers and a red action-indicator position are illustrated. Match the drawing to the ordered body configuration; do not apply its body length to a different housing.

Product Information

ItemSpecification
ModelSH-NJK5002AB / NJK-5002AB
Output selectionPNP, four-wire
Output functionsSeparate NO and NC outputs
Working supplyDC 6–36 V
Nominal magnetic detection distance10 mm ±10%, with the specified magnetic target
Standard test targetØ12 × 2 mm permanent magnet
ThreadM12 × 1

Before Ordering

  • Confirm the four-wire PNP version and required NO/NC functions.
  • Match the magnetic target and operating position, threaded fixing, body length and cable routing.
  • Confirm the actual supply, terminal assignment, load and ordered cable arrangement before connection.

Frequently Asked Questions

What output version is this selection?

The NJK5002AB selection uses a four-wire PNP output arrangement with separate NO and NC functions.

Does it detect any metal target?

Choose and position the permanent-magnet target for the magnetic switch; do not substitute a nonmagnetic target solely because it is metal.

Can one outline drawing define every pictured housing?

Match the short-body drawing to the exact ordered housing and check its body length and mounting arrangement.

What must be confirmed before installation?

Confirm the model, PNP controller input, supply, output connections, magnetic operating position and cable routing.
