G03 Elevator Governor Installation Base
Adjustable installation base documented for elevator governor mounting applications.
Model and Product Features
Commercial model G03. The steel base provides an elongated adjustable mounting arrangement and multiple hole and slot positions shown in the original AODEPU drawing.
Product and Technical Views
Product Information and Specifications
| Item | Specification |
|---|---|
| Product type | Elevator governor installation base |
| Model | G03 |
| Overall length | 635 mm |
| Overall height | 120 mm |
| Adjustment range | 335–375 mm |
| Long slots | 4 × 13 × 65 mm |
| Base overall width | 320 mm |
| Base inner widths | 280 mm and 200 mm |
| Round mounting holes | 4 × Ø10 mm |
| Large holes | 2 × Ø40 mm |
Before You Buy
Select the G03 base by the required adjustment range, hole pattern and available mounting envelope. Governor applicability must be established from the matching installation design.
Frequently Asked Questions
What is the G03?
G03 is an elevator governor installation base documented in the Ningbo AODEPU governor catalog.
What adjustment range is shown for the base?
The original G03 drawing shows an adjustable range of 335–375 mm.
Which mounting features are specified?
The drawing lists four 13 × 65 mm long slots, four Ø10 mm round holes and two Ø40 mm large holes.
