SH-KS-2 / 2801
Main product · round key-operated switch
| Product type | Configuration | Order confirmation |
|---|---|---|
| Elevator button lock / key-operated switch | Round type. The corresponding 2801 supplemental page states 1 NO + 1 NC. Drawing callouts: Ø22 face, 37 mm body depth, 3/4"–27 thread, Ø19 opening with 16 mm across flats, A/B positions 90° apart and terminals numbered 1–4. | Confirm voltage/current rating, terminal-to-contact mapping, switching sequence, key-removal position, lock code and supplied key quantity. |
information boundary: the 1 NO + 1 NC statement is a corresponding 2801 webpage reference, not a terminal map or formal electrical rating. No brand provenance or authenticity claim is inferred.
